The premium micro Secure Digital (microSD) card is fully compliant with the standards released by the SD Card Association.
The premium grade (PG) microSD card comes with an 8-pin interface, designed to operate at a maximum frequency of 208MHz. It can alternate communication protocol between the SD mode and SPI mode. It performs data error detection and correction with very low power consumption. MicroSD cards are one of the most popular removable storage cards today due to their high performance, reliability and wide compatibility.
Click Here to shop more AMP, INC. products.
Grade | Extended Industrial |
Interface | Micro SD |
NAND Type | QLC |
Operating Temp | -40ºC - 95ºC |
Speed (Sequential Read, MB/s) | 100.84 |
Speed (Sequential Write, MB/s) | 95.58 |
Speed (Sequential Write, MB/s) | 95.58 |
Speed (Random Read, 4k IOPS) | 9541 |
Speed (Random Write, 4k IOPS) | 3201 |
Hardware Secure Erase, Write Protect | Supported |
ECC (ECC/non-ECC) | Supported |
Module Height | 2.1mm |
Module length | 32mm |
Speed | U3 |
Pins | 8 |
