MTA18ASF2G72PZ-2G6 Micron 16GB DDR4-2666 ECC RDIMM
MTA18ASF2G72PZ-2G6 is a 16GB DDR4-2666 registered ECC RDIMM manufactured by Micron. This 288-pin server memory module is designed for compatible servers, enterprise workstations, storage appliances and data-center platforms that support registered DDR4 memory.
The module operates at 2666 MT/s with CL19 timing and the standard DDR4 voltage of 1.2V. In addition, its registered ECC architecture supports memory-error detection and correction in compatible systems. Its single-rank 1Rx4 organization is intended for server platforms that support this specific module configuration.
Key Features
- 16GB DDR4 memory capacity
- DDR4-2666 data rate
- PC4-21300 industry designation
- 288-pin RDIMM form factor
- Registered ECC architecture
- Single-rank 1Rx4 organization
- CL19 timing
- Standard 1.2V operation
- Onboard register and SPD functionality
- Manufactured by Micron
- One 16GB module per unit ordered
Common Applications
- Enterprise server memory upgrades
- Replacement of an identical Micron RDIMM
- Compatible data-center systems
- Enterprise storage appliances
- Virtualization and database servers
- ECC-capable professional workstations
Is MTA18ASF2G72PZ-2G6 Compatible With My System?
Before ordering, verify that your server or workstation supports 288-pin DDR4-2666 registered ECC RDIMM memory. A DDR4 slot alone does not confirm compatibility. The processor, chipset, motherboard and firmware must support registered ECC modules.
This module is not interchangeable with non-ECC UDIMM, ECC UDIMM, SODIMM or LRDIMM memory. RDIMMs and LRDIMMs should not be mixed unless the system manufacturer explicitly documents support for that configuration.
This module uses a single-rank 1Rx4 organization. The “1R” designation means the module contains one logical rank, while “x4” describes the width of its DRAM devices. It does not indicate the number of modules included. Each unit ordered includes one 16GB RDIMM.
When adding this module to existing memory, compare the complete part number and match the capacity, speed, ECC type, registered architecture, rank and device organization. For best results, follow the server manufacturer’s approved memory population rules and qualified-vendor list.
MTA18ASF2G72PZ-2G6 Specifications
Capacity | 16GB |
Memory Type | DDR4 |
ECC | ECC |
DIMM Type | RDIMM |
Rank | 1Rx4 |
Speed | 2666 |
Voltage | 1.2V |
Depth | 2G |
Width | 72 |
Pins | 288-pin |
Frequency | 1333 |
Temperature | Commercial Temp. 0°C - 85°C |
Module Name | PC4-21300V-R |
Made By | Micron |
Need Help Confirming Compatibility?
Compare the complete part number and specifications with your existing module or system documentation. For assistance selecting compatible server memory, contact AMP before ordering.
